Go to the source code of this file.
Classes | |
| struct | RCOIPv1CmdSetAnalogChannels |
| SetAnalogChannels command message structure. More... | |
| struct | RCOIPv1ReplyReceiverStatus |
| ReceiverStatus reply message structure. More... | |
Macros | |
| #define | RC_VERSION1 1 |
| #define | RC_VERSION RC_VERSION1 |
| #define | RCOIP_DEFAULT_REPLY_INTERVAL 1000 |
| #define | RCOIP_DEFAULT_FAIL_INTERVAL 2000 |
| #define | RCOIP_DEFAULT_KEEPALIVE_INTERVAL 1000 |
| #define | RCOIP_DEFAULT_RECEIVER_UDP_PORT 9048 |
Typedefs | |
| typedef RCOIPv1CmdSetAnalogChannels | RCOIPCmdSetAnalogChannels |
| typedef RCOIPv1ReplyReceiverStatus | RCOIPReplyReceiverStatus |
Macro Definition Documentation
◆ RC_VERSION
| #define RC_VERSION RC_VERSION1 |
This is the default (latest) version of the RCOIP protocol
◆ RC_VERSION1
| #define RC_VERSION1 1 |
Indicates Version 1 of RCOIP protocol
◆ RCOIP_DEFAULT_FAIL_INTERVAL
| #define RCOIP_DEFAULT_FAIL_INTERVAL 2000 |
Defines the default maximum time in milliseconds between that will be regarded as a loss of connection by either the receiver or the transmitter
◆ RCOIP_DEFAULT_KEEPALIVE_INTERVAL
| #define RCOIP_DEFAULT_KEEPALIVE_INTERVAL 1000 |
Defines the default time in milliseconds between keepalaive Command messages sent by the receiver. If no messages are transmitted for more than this period of time a keepalive Command message will be sent to the receiver.
◆ RCOIP_DEFAULT_RECEIVER_UDP_PORT
| #define RCOIP_DEFAULT_RECEIVER_UDP_PORT 9048 |
Defines the default RCOIP receiver UDP port number 9048 is controlled by Open System Consultants
◆ RCOIP_DEFAULT_REPLY_INTERVAL
| #define RCOIP_DEFAULT_REPLY_INTERVAL 1000 |
Defines the default maximum time in milliseconds between Reply messages sent by the receiver
Typedef Documentation
◆ RCOIPCmdSetAnalogChannels
This is the preferred type to use to refer to the latest version of the RCOIPCmdSetAnalogChannels message
◆ RCOIPReplyReceiverStatus
This is the preferred type to use to refer to the latest version of the RCOIPReplyReceiverStatus message
